SPEEDWAY SW-335 Single Needle Cylinder Bed Heavy Duty Unison Feed Walking Foot Sewing Machine Assembled with Servo Motor, Table and Stand Included
SPEEDWAY SW-335 Single Needle Cylinder Bed Heavy Duty Unison Feed Walking Foot Sewing Machine Assembled with Servo Motor, Table and Stand Included
Cylinder-bed sewing machine for industry and handcraft
The SPEEDWAY 335 is an universal cylinder-bed machine for use in small leather goods, leather garments, upholstery, shoes, etc. Working on tubular or pre-attached articles and standard sewing work on leather wear, bags and leather craft articles.
SPEEDWAY SW-335
Assembled, ready to sew!
Features
Universal cylinder-bed machine for use in small leather goods, leather garments, upholstery, shoes, etc
Working on tubular or pre-attached articles and standard sewing work on leather wear, bags and leathercraft articles.
Cylinder-bed machine for working on tubular or pre-attached articles
Very good feeding properties due to the unison feed
Excellent sewing quality with high performance and sewing reliability
Precise and consistent stitch setting at large spectrum of materials/fabrics
Rugged and durable machine construction - Easy to maintain machine concept
The high top feed lift (7 mm) allows trouble-free sewing of thick materials and an easy sewing over cross seams
Easy loading and unloading - even of bulky material - due to a high fabric clearance of 15 mm
Distance of the front edge of the cylinder arm to the needle: 9 mm - Cylinder arm diameter: 45 mm
Needle system: 134-35 LR
Needle size: 80 -100 Nm
Max. sewing speeds: 2.800 s.p.m
Max. stitch length: 8,0 mm
Top feed stroke: 7,0 mm
Stitch type: 301 (Lockstitch)
Thread type: synth. 40/3
Clearance under the sewing foot: max. 15,0 mm
Connection voltage: single-phase a.c. 110 V, 50/60 Hz
